Support second display with adjustable swivel angle
20-90° adjustable main display
adjustable main displ
Effective Heat Dissipation System
I/O interface for easy peripherals connection
Built-in wireless LAN for remote communication
Two 2.5" SATA hard disk bays and one CompactFlash card slot for storage
IP-64 compliant front panel
Specifications
EP-265-910
EP-265-GM45
EP-267-910
EP-267-GM45
LCD Size
15"
15"
17"
17"
CPU
Intel® Celeron® M 1GHz / 512KB L2 cache
Intel® Celeron® M 2.0GHz / 1MB L2 cache
Intel® Celeron® M 1GHz / 512KB L2 cache
Intel® Celeron® M 2.0GHz / 1MB L2 cache
Chipset
Intel® 910GMLE + ICH6-M
Intel® GM45 + ICH9M
Intel® 910GMLE + ICH6-M
Intel® GM45 + ICH9M
Graphic
Integrated in 910GMLE with DB-15 VGA output
Integrated in GM45 with
DB-15 VGA output
Integrated in 910GMLE with DB-15 VGA output
Integrated in GM45 with
DB-15 VGA
output
Memory
Built-in 1GB DDR2 memory system supports 2 x 240 pin dual channel DDR2 400/533MHz up to 2GB
Built-in 1GB DDR2 memory system supports 2 x 240 pin dual channel DDR2 667/800MHz up to 2GB
Built-in 1GB DDR2 memory system supports 2 x 240 pin dual channel DDR2 400/533MHz up to 2GB
Built-in 1GB DDR2 memory system supports 2 x 240 pin dual channel DDR2 667/800MHz up to 2GB
Max Resolution
1024 x 768
1280 x 1024
Brightness (cd/m²)
350
300
Contrast Ratio
400:1
800:1
LCD Color
262K
16.7M
Pixel Pitch (mm)
0.297(H) x 0.297(V)
0.264(H) x 0.264(V)
Viewing Angle (H-V)
120/ 100
160/ 160
Backlight MTBF
50000 hrs
Touch Screen
Resistive Type 5-Wire, Support RS-232 interface. Capacitive Type supported by order
HDD
2 x 2.5" SATA HDD Bay
SSD
1 x CF Type II slot
I/O Interface
Display
1 x VGA Port
Powered USB
7 x USB 2.0
2 x 5V PoweredUSB on the rear panel
2 x 5V PoweredUSB on the bottom panel
1 x 12V PoweredUSB on the rear panel
1 x 12V PoweredUSB on the bottom panel
1 x 24V PoweredUSB on the bottom panel
Powered COM
4 x COM Port with LED indicators
3 x 5V/ 12V Powered COM on the bottom panel (COM3/ COM4/ COM5)
1 x 5V/ 12V Powered COM on the rear panel
(COM1)
Cash Drawer Port
2 x 12V/ 24V RJ-11 connectors for cash drawer
LPT
1 x DB-25
LAN
1 x giga LAN
Wireless
802.11 a/b/g with PIFA antenna, PCIe interface
Audio
3W + 3W amp. audio jack on the bottom
Power Switch
1 x 12V/ 24V 2x5 pin DC-IN Power Jack
1 x Power Switch with LED on Front Panel
Quick Buttons
Brightness & Volume control
Power
Adapter
252W Power Adapter (ACE-D825A-H-RS)
Input
12V/24V DC in
Output
12VDC at 4.0A
12VDC at 4.2A
12VDC at 4.9A
12VDC at 5.3A
Consumption
66W
N/A
66W
N/A
Construction
ABS + PC Plastic Front Frame Aluminum Alloy Chassis
Color
Black
Operation Temperature
0~40˚C
IP Level
IP64 (Front Panel)
Safety & EMI
CE / EMC / FCC / CB / UL
Dimension (WxHxD)
373 x 390 x 335 mm
408 x 414 x 350 mm
Net Weight
8.3 Kg
9.8 Kg
Ordering
Info
EP-265 Series
EP-265-910-10G/WT-R/1GB
15" 350cd/m² XGA POS PC with Celeron® M 1.0GHz 512K cache CPU,1GB DDR2 RAM, 802.11 b/g wireless module, touch screen, RoHS
EP-265-GM45-CM550/WT-R/1GB
15" 350cd/m² XGA POS PC with Celeron® 2.0GHz 1MB cache CPU,1GB DDR2 RAM, 802.11 b/g wireless module, touch screen, RoHS
EP-267 Series
EP-267-910-10G/WT-R/1GB
17" 300cd/m² SXGA POS PC with Celeron® M 1.0GHz 512K cache CPU,1GB DDR2 RAM, 802.11 b/g wireless module, touch screen, RoHS
EP-267-GM45-CM550/WT-R/1GB
17" 300cd/m² XGA POS PC with Celeron® 2.0GHz 1MB cache CPU,1GB DDR2 RAM, 802.11 b/g wireless module, touch screen, RoHS
