| Features |
 |
Unique true flat panel without rim |
| |
Stylish design fuses aluminum and plastic |
| |
Adjustable view angle of customer display |
| |
Customized color synchronizing your shop and corporation identity |
| |
Intel® Pineview D 410 / D510 1.66GHz CPU integrated |
| |
38.1cm ( 15” ) projected capacitive touchscreen |
| |
17.8 cm (7") second display supported |
| |
Security mechanism on HDD position |
| |
IP66 at front panel waterproof approved |
| |
Support 100 x 100 VESA standard |
| |
Connected for optional peripherals: Programmable keyboard / Omni-directional scanner / Handheld scanner supported / USB dongle support of WiFi / 3.5G |
| Main Board |
CPU |
Intel® Pineview D410 (Single Core) 1.66GHz with L2 Cache 512KB
Intel® Pineview D510 (Dual Core) 1.66GHz with L2 Cache 1MB |
| Chipset |
Intel® Pineview + ICH8M |
| System Memory |
1 x SO-DIMM DDRII 667, up to 2GB |
| Display |
TFT LCD |
38.1cm (15") |
| Brightness |
250nits |
| Resolution |
1024 x 768 |
| Touch Screen |
True Flat Projected Capacitive Technology / True Flat 5-Wire Resistive |
| Storage |
HDD Type |
1 x SATA 6.4cm (2.5'')HDD |
| Compact Flash Type |
1 x Slot Type II |
| I/O Ports -External |
DC Input |
1 x Mini Din 4P (DC 12V only) |
| Cash Drawer |
1 x RJ-11 (Power Pin 12V) |
| Network (LAN) |
1 x Gigabit Ethernet by RJ-45 |
| USB Port |
4 x USB 2.0 |
| Serial Port |
4 x RS-232
COM1/2 : DB-9, RS-232, Pin9 w/RI/5V/12V Selectable by BIOS
COM3 : RJ-48 for VFD, RS-232, Pin10 w/RI/5V/12V Selectable by BIOS
COM4 : DB-9, RS-232, Pin9 w/RI/5V/12V Selectable by BIOS (optional) |
| PS/2 Port |
1 x PS/2 connector for Keyboard |
| LPT Port |
1 x DB-25 Printer Port |
| VGA Port |
1 x DB-15 VGA Port (optional) |
| I/O Ports -Internal |
Card Reader & iButton |
COM5 : Internal Pin header for Card Reader & iButton |
| Audio |
AC 97 2.0 compliant, 2W Speaker x 2 |
| Bus Expansion |
1 x Mini-PCI-E Slot |
| Compliance |
IP 66 |
| System Management |
Desktop Management Interface (DMI) |
| Preboot Execution Environment (PXE) |
| Wake on LAN (WoL) |
| Advanced Configuration and Power Interface (ACPI) |
| OS Support |
Windows 7, Windows POSReady 2009, WEPOS, Windows XP Pro for Embedded, Fedora(Linux) |
| Power Supply |
External adapter, DC Model:80 Watts, Voltage:+12VDC 6.6A max. |
| Material |
Main Unit: Die-casting aluminum ; I/O Cover:Plastic |
| Color |
Main Unit: Gray *Customized color for plastic parts |
| Certifications |
CE, FCC, Class-A, RoHS, WEEE |
| Dimension( Wx H x D ) |
370 x 287 x 55mm |
| Weight |
4.5 Kg (Aluminium Base: 1 Kg ) |
| VESA Mounting |
100 x 100 mm |
| Operating Temperature |
0ºC ~ 40ºC, 10% ~ 90% RH, non-condensing |
| Storage Temperature |
-20ºC ~ 60ºC, 10% ~ 90% RH, non-condensing |
