| Specifications |
| Output |
| Voltage (Max.load) |
+5V |
+12V |
-12V |
+3.3V |
+5VSB |
| IDDUPS-6364120A |
10A |
4A |
0.3A |
8A |
2A |
| IDDUPS-636260A |
10A |
3A |
|
|
0.5A |
|
| Input |
6VDC to 36VDC |
| Battery Charge Voltage |
12V ~ 36V |
| Efficiency |
up to 90% |
| Dimensions |
60mm x 160mm |
Weight
|
NW: 98g (IDDUPS-6364120A),
75g (IDDUPS-636260A) |
| Operating Temperature |
-20ºC ~ 85ºC |
| Storage Temperature |
-40ºC ~ 125ºC |
| |
 |
| IDDUPS-6364120A-R10 |
120W ATX DC/DC 6-36VDC input, 12V, 5V, 3.3V, -12V and 5VSB Power Module with UPS |
| IDDUPS-636260A-R10 |
60W ATX DC/DC 6-36VDC input, 12V, 5V and 5VSB Power Module with UPS |
| BAT-LI-2S1P3000 |
Smart Battery, Li-Polymer, 2S1P, 3000mAH |
| CB-5PSBC-RS |
20cm Cable to SBC Power Input |
| CB-JST3P001-RS |
30cm 5VSB, PS_ON Wire to SBC |
| CB-3PSATA-RS |
10cm Cable for SATA Power |
| CB-3PIDE-RS |
10cm Cable for IDE HDD Power |
| CB-MD4P4-RS |
20cm Cable for FSP0601AD101C 60W/ UP0451E12P 45W/UP0251E12PL 25W AC-DC adapter |
| CB-MD4P4-RS |
60W/ UP0451E12P 45W/UP0251E12PL 25W AC-DC adapter |
| CB-NOLP4-RS |
20cm Cable for Terminal Block DC Input |
| CB-ATX20P-RS |
30cm 20 Pins ATX to 20 Pins ATX Cable |
